KKPIT Belief2 1/8 Scale RC Ultra-Fast Coreless Waterproof 28kg Servo

Overview

KKPIT Belief2 is engineered for one purpose: to deliver unparalleled speed and precision on the track. Powered by a high-quality coreless motor, it boasts an incredible response time of just 0.075s/60° at 8.4V. This blistering speed, combined with a robust 32kg/cm of torque, makes it the ultimate choice for drivers who demand instant, accurate control.

Built to withstand the rigors of competition, this servo features an IP67 waterproof rating and a durable all-stainless steel gear set. Its custom-molded waterproof seals and reinforced dual-bearing design ensure long-lasting, reliable performance, whether you’re racing in the dry or tearing through mud and water. The HV-CLS-0732 is the perfect upgrade for any serious racer looking to shave precious milliseconds off their lap times.

Ideal Applications

Based on its speed-focused design, KKPIT Belief2 is best suited for:

• 1/8 Scale On-Road and Off-Road Racing: The combination of extreme speed and high torque is ideal for competitive buggies and truggies where every millisecond counts.
• High-Speed RC Vehicles: Perfect for any model where quick, precise steering is more critical than maximum brute-force torque.
• Nitro RC Throttle/Brake Control: Its rapid response and durability make it an excellent choice for managing high-power nitro engines.
• Competitive Drifting: The servo’s speed and accuracy are crucial for executing rapid counter-steering maneuvers.

Key Features

• Extreme High-Speed Performance: Achieves a blazing 0.075s/60° response for lightning-fast steering adjustments.
• High-Torque Coreless Motor: Delivers powerful, consistent torque of up to 32kg/cm with the quick-response benefits of a coreless design.
• IP67 Waterproof Rating: Fully protected against dust and water immersion, perfect for all-weather racing.
• All-Stainless Steel Gears: Built to withstand the high-frequency and high-impact demands of racing.
• 180° Max Angle Design: Provides a wider range of motion for superior control and tuning.
• Dual-Bearing Structure: Enhances durability and smooth operation under heavy load.

Specifications

• Dead Band: 2μs 1520μs / 330Hz
• Motor: Coreless Motor
• Operating Speed (6.0V): 0.10s / 60°
• Operating Speed (7.4V): 0.08s / 60°
• Operating Speed (8.4V): 0.075s / 60°
• Stall Torque (6.0V): 22kg/cm (305.58 oz/in)
• Stall Torque (7.4V): 28kg/cm (388.92 oz/in)
• Stall Torque (8.4V): 32kg/cm (444.48 oz/in)
• Dimensions: 40 × 20 × 39.85mm (1.57″ × 0.78″ × 1.56″)
• Weight: 89g (0.2lb)
• Connector Wire Length: 315mm (12.4″)
• Bearing: 2BB
